Common features

• DVB-C, J83a/b/c support.
• Full QAM-order support.
• Variable channel-alpha filtering.
• Variable symbol-rates (Max ~7MSym).

Cyclone-III Starter Kit specifics

• Bitec Broadcast Video Daughter Card.
• External RAM required for DOCSIS 3.0 interleaving.
• Single IF analog output (Max ~70MHz).
• Dual ASI Transport stream inputs.

Cyclone-III FPGA Development Kit specifics

• Bitec Broadcast Video Daughter Card.
• Single IF analog output (Max ~70MHz).
• Dual ASI Transport stream inputs.

Cyclone-III DSP Development Kit specifics

• Single IF analog output (Max ~40MHz).
• Forced NULL Transport stream inputs.

Stratix-II DSP Development Kit specifics

• Dual I+Q analog outputs (Max ~40MHz)
• Forced NULL Transport stream inputs.
